X6
23.8'' HD Sound System Frameless AIO
Color：Silver white
Size：23.8 Inch
- Function
- Parameter
| Main | |
| Model | X6 |
| Screen size | 23.8 Inch |
| Color | Silver white |
| Product Type | AIO Barebone |
| Product Position | Home &Office |
| Mainboard | |
| Mainboard Type | H81,H110 ( Thin mini ITX) |
| CPU | |
| CPU |
Support Intel Haswell Celeron/ Pentium/ Core i3/i5/i7 (H81) Support Intel Skylake Celeron/ Pentium Core i3/i5/i7 (H110) |
| Memory | |
| Memory type | 2xSO-DIMM 1.5V/1.35V( DDR3) /1.2V(DDR4), MAX 16GB |
| Hard Drive | |
| Storage | 1x m-SATA, SSD/HDD |
| Display | |
| Screen ratio | 16:9 |
| Best resolution | 1920*1080 |
| Backlight | LED Backlight |
| Response time | 2ms |
| Brightness | 250nits |
| Viewing angle | 178° (L/R) 178° (U/D) |
| Graphic | |
| Graphic | Intel HD Graphic，do not support Discrete Graphics |
| I/O port | |
| Front I/O port | USB2.0*1 |
| Rear I/O port | HDMI*1、VGA*1、USB3.0*2、USB2.0*2、RJ45 Gigabit LAN*1、AUDIO IN/OUT |
| Features | |
| Touch | N/A |
| Chipset | H81/H110 |
| Optical Drive | N/A |
| WiFi | 802.11 b/g/n ( PCI-E) |
| Camera | N/A |
| Speaker | Built - in high quality 2-channel stereo speaker |
| Power supply | 110W~220V 90W AC- DC Adapter |
| Power Consumption | |
| Power consumption | 90W |
| Working temperature | -20°~50C |
| Specification | |
| Unit Dimension | L540*W415*D55mm |
| VESA | N/A |
| Power cord | Included |
| Power Specification | 19V 4.74A |
|
|
|
| Accessories | |
| Standard accessories | Packinglist：AIO Barebone System, Power cables /screws, external power supply, instruction manual |
|
|
|
|
|
|
