X400/X700
Super Slim Frameless Gaming AIO
Color：Silver white/Gray
Size：23.8/27 Inch
- Function
- Parameter
| Mainbody | |
| Model | X400/X700 |
| Screen size | 23.8/27 Inch |
| Color | Silver white / Gray |
| Product Type | Barebone AIO |
| Position | Office/Home |
| Mainboard | |
| Mainboard Type | OEM H110(LGA 1151) |
| CPU | |
| CPU |
Support Intel Skylake Celeron/Pentium/Ccore i3/i5/i7(H110) |
| Memory | |
| Memory | 2xDDR4 SO- DIMM, MAX 16GB |
| Hard Drive | |
| Storage | 1x m-SATA, 2x SATA |
| Display | |
| Screen ratio | 16:9 |
| Best Resolution | 1920*1080 |
| Backlight | LED Backlight |
| Response time | 2ms |
| Brigttness | 250nits |
| Viewing angle | 178°(L/R) 178° (U/D) |
| Graphic | |
| Graphic | Discrete Graphic |
| I/O Port | |
| Front I/O port | USB2.0*2 |
| Rear I/O port | SD Card Reader、HDMI*2、VGA*2、USB3.0*2、USB2.0*2、RJ45 Gigabit LAN*1、AUDIO IN/OUT |
| Features | |
| Touch | N/A |
| Chipset | Support Intel Skylake Celeron/Pentium / Core i3/i5/i7 (H110) |
| Opyical Drive | N/A |
| WiFi | 802.11 b/g/n (PCI-E) |
| Camera | N/A |
| Speaker | Built- in high quality 2- channel stereo speaker |
| Power supply | 110V-220V 180W AC-DC Adapter |
| Power Consumption | |
| Power consumption | 180W |
| Working temperature | -20°~50°C |
| Specifications | |
| Unit Dimension | L539*W390*D65mm |
| VESA | N/A |
| Power cord | Included |
| power specifications | 19V 9.47A |
|
|
|
| Accessories | |
| Standard accessories | Packing list : AIO Barebone System, power cables/screws, external power supply, instrution manual |
|
|
|
|
|
|
